Hey everyone,
I’m currently working through a great tutorial series on youtube for ROS2. Unfortunately, I ran into a bit of an issue with a race condition in a launch file. The controller managers were timing out before Gazebo was able to launch.

Controller manager not available

The author offers a suggestion to try using OnProcessExit to work around this but unfortunately it did not work for me. The comments on the video seem to suggest that a few others also hit this problem.

I did a bit of Googling and found an alternative way to add a delay on startup using TimerAction. Using the following code as a replacement for the original launch actions seems to work:

import os

from ament_index_python.packages import get_package_share_directory


from launch import LaunchDescription
from launch.actions import IncludeLaunchDescription
from launch.actions import TimerAction
from launch.launch_description_sources import PythonLaunchDescriptionSource
from launch.actions import RegisterEventHandler
from launch.event_handlers import OnProcessExit

from launch_ros.actions import Node



def generate_launch_description():


    # Include the robot_state_publisher launch file, provided by our own package. Force sim time to be enabled
    # !!! MAKE SURE YOU SET THE PACKAGE NAME CORRECTLY !!!

    package_name='my_bot' #<--- CHANGE ME

    rsp = IncludeLaunchDescription(
                PythonLaunchDescriptionSource([os.path.join(
                    get_package_share_directory(package_name),'launch','rsp.launch.py'
                )]), launch_arguments={'use_sim_time': 'true'}.items()
    )

    # Include the Gazebo launch file, provided by the gazebo_ros package
    gazebo = IncludeLaunchDescription(
                PythonLaunchDescriptionSource([os.path.join(
                    get_package_share_directory('gazebo_ros'), 'launch', 'gazebo.launch.py')]),
             )

    # Run the spawner node from the gazebo_ros package. The entity name doesn't really matter if you only have a single robot.
    spawn_entity = Node(package='gazebo_ros', executable='spawn_entity.py',
                        arguments=['-topic', 'robot_description',
                                   '-entity', 'my_bot'],
                        output='screen')

    # This helps to address race conditions on startup for the
    # controller managers. Note that we are exporting delayed_controller_manager_spawner
    # instead of just diff_drive_spawner.
    delayed_controller_manager_spawner = TimerAction(
        period=10.0,
        actions=[
            Node(
                package="controller_manager",
                executable="spawner.py",
                arguments=["diff_cont"],
            ),
            Node(
                package="controller_manager",
                executable="spawner.py",
                arguments=["joint_broad"],
            )
        ],
    )


    # Launch them all!
    return LaunchDescription([
        rsp,
        gazebo,
        spawn_entity,
        delayed_controller_manager_spawner,
    ])

This Github link has a good example of how to do this for another similar project: https://github.com/ros2/launch_ros/blob/b84b72748e22d8fd648151d96478d19305c96c82/launch_testing_ros/test/examples/check_node_launch_test.py#L36-L45.
